Designed for use on the Ultimate, Formula, APEX and APEX-Pro Aluminium Cockpits

Features:

  • Easy Adjust for Height and Reach with quick adjust Hand Nut system.
  • Includes Cable Management bar to ensure a fuss free neat and tidy Cockpit.
  • Clever Cable Management kit utilizes the Cable Management bar with a combination of double-sided Velcro and Profile inserts.
  • Fits Standard 18 – 65″ VESA compatible Televisions and Monitors
  • Utilizes 100×100/100×200/200×200/200×300/300×300/300×400 Flat Mounting bracket system.
  • Fully Powder Coated black for a stylish durable finish.
  • Features 45×45 Aluminum Profile and Internal M12 connections for additional stability for large screens.
  • Direct connection for Triple Screen allows neat Al on One frame packaging.

Compatibility:

VESA Mounting patterns with FLAT back panel surface and fitting holes for: 100h×100w; 200h×200w; 200h×300w; 200h×400w; 300hx300w; 300hx400w

NOTE
  • The VESA Screen Mount PLUS is not supplied with a VESA bracket allowing 50×50; 75×75; and 85×85 VESA mounting patterns. This can be supplied at an additional cost.
  • Additional connecting elements may be needed for using Samsung 49″ Curved monitors. Enquire for more details.
  • Additional connecting elements may be needed for using Dell & Samsung 27 % 32″ Curved monitors. Enquire for more details.
  • Additional connecting elements will be needed 400×400 VESA mounting patterns. If unsure, check your screen mounting pattern to arrange the alternative brackets. Enquire for more details.

Options:

Dimensions: 945 x 690 x 180

Weight without screen: 5.5kg

Max Screen weight: 26kg

See Video guide here

VESA Screen Mount PLUS for 18-65″ Screens

Add Large Screen capability with up to 250mm height and reach adjustability with the VESA Screen mount Plus. Designed to fit the SimCave Ultimate, Formula, Apx-Pro and APEX Aluminium SimulatorCockpits.

R3000,00

Available on back-order

VESA Screen Mount PLUS for 18-65" ScreensVESA Screen Mount PLUS for 18-65″ Screens
R3000,00

Available on back-order
